4 Core |
|
|
4 Core Thin Wall Multicore Cable Description:- Individual cores are manufactured to ISO 6722 : 2002 (Class B) 105ºC with plain copper conductors over sheathed with flexible PVC. Individual Core Colours:- Brown, Green, Red & White. Temperature Range: -15ºC to +70ºC |
Product Prices & Dimensions
| Part No | CSA (mm?) |
Stranding | O.D (mm) |
Current Rating (Amps) |
Reel Sizes (m) |
List Price (exc VAT) |
|---|---|---|---|---|---|---|
| MT4-075-B-30 | 4 x 0.75 | 24 x 0.2 | 5.8 | 14.0 | 30 | £1377.78 /1000 |
| MT4-075-B-100 | 4 x 0.75 | 24 x 0.2 | 5.8 | 14.0 | 100 | £1249.90 /1000 |
| MT4-100-B-30 | 4 x 1.0 | 32 x0.2 | 5.8 | 16.5 | 30 | £1722.70 /1000 |
| MT4-100-B-100 | 4 x 1.0 | 32 x 0.2 | 5.8 | 16.5 | 100 | £1573.62 /1000 |
